IA II Crank Scraper

IA II Crank Scraper
Without dipstick tube hole*
Price: $42.00 per set
Part Number: IAII-CS
contact us

This new crank scraper is designed for the IA II block or race applications with 4 bolt or splayed caps.

  • Laser cut NON - BENDABLE 18 gauge steel
  • Keeps oil down in the pan with better sealing
  • Increases power on all high performance Pontiac V-8ís
  • Will clear IA II splayed caps or regular blocks using aftermarket main caps without modifications
  • Easy Installation
  • Elongated holes to adjust distance from scraper to crank for custom fit

Highly recommend for use with the IA II Windage Tray

Buy both for better racing performance!

Part# - IAII-WTRCS $179.00

IA II Windage Tray IA II Crank Scraper

IA II Windage Tray and IA II Crank Scraper (without dipstick tube hole). Fasterners for windage tray included.

Installation Notes

Install tray by applying pressure until studs appear through installation holes.

Screw on nuts and tighten. Windage tray may need to be shimmed to clear certain stroke/rod combinations.

Shims should be made from rectangular stock - washers not recommended. Shimming more then 1/4" may not allow the oil pan to fit. Rotate crankshaft several times and check for clearance.

It may be necessary to straighten louvers to clear connecting rods. Trays may need clearance by bending for certain oil pumps. It is best to fit all components.

Note: If using a dipstick tube, drill a provisional hole in the scraper.


Packaging and Handling $4.95 each order
Plus shipping charges

Crating charge for overseas shipping is $125.00†per crate. F.O.B. point of shipment origin.
